The Woods Timer 50007 is a versatile 24-hour digital timer designed for automating household devices. It features CSA certification‚ CFL compatibility‚ and an easy-to-use interface for programming.
1.1 Overview of the Woods Timer 50007
The Woods Timer 50007 is a 24-hour digital timer designed to automate household devices like lamps‚ fans‚ and holiday lights. It offers a slim‚ space-saving design and CSA certification‚ ensuring safety and reliability. The timer is compatible with CFL and LED lights‚ making it energy-efficient. With a user-friendly interface‚ it allows easy programming of on/off times. The device comes with a clear digital display and simple controls‚ enabling seamless operation. It is ideal for indoor use and includes a comprehensive manual for setup and troubleshooting.
1.2 Key Features of the Woods 50007 Timer
The Woods 50007 Timer boasts CSA certification for safety and reliability‚ ensuring compatibility with CFL and LED lights. It features a 24-hour programming cycle‚ allowing users to set automatic on/off times. The timer includes a backlit digital display for easy readability and a slim design that fits dual outlets. It also offers a battery backup to retain settings during power outages. These features make it an efficient and user-friendly solution for controlling household devices like lamps‚ fans‚ and holiday lights.
Installing the Woods Timer 50007
Install the Woods Timer 50007 by plugging it into a duplex outlet. Its slim design allows both timers to fit on the same outlet.
2.1 Unpacking and Preparing the Timer
Begin by carefully unpacking the Woods Timer 50007 from its packaging. Inspect the timer for any visible damage. Remove any protective covering from the screen. Insert the included batteries according to the polarity markings. Ensure the timer is placed on a stable surface. Before plugging it in‚ review the manual to familiarize yourself with its buttons and features. This preparation ensures smooth installation and operation.
2.2 Plugging in the Timer and Initial Setup
Plug the Woods Timer 50007 into a nearby outlet‚ ensuring it fits securely. Locate a duplex outlet to accommodate both timers if using the 2-pack. Press and hold the SET button for 2 seconds to activate the timer. The hour will flash; use the + or ౼ buttons to set the current hour and minutes. Once set‚ the timer will automatically enter standby mode‚ ready for programming. Ensure the time is accurate for proper operation of scheduled events.
Programming the Woods Timer 50007
The Woods Timer 50007 offers a user-friendly programming interface for setting on/off times. It supports up to 24-hour scheduling and is compatible with CFL lights.
3.1 Setting the Current Time
To set the current time on the Woods Timer 50007‚ press and hold the SET button for 2 seconds. The hour will flash‚ allowing you to adjust it using the up or down buttons. Once the hour is set‚ the minutes will flash next. After confirming the time‚ the timer will automatically save the settings. This process ensures accurate scheduling for your devices. The timer is CSA certified and compatible with CFL lights‚ making it a reliable choice for automating household appliances. Follow these steps carefully for proper functionality.
3.2 Programming On/Off Times
To program on/off times for your Woods Timer 50007‚ press the SET button to enter programming mode. Use the up or down buttons to select the desired day(s) and time for the device to turn on or off. The timer allows you to set up to 20 on/off events‚ providing flexibility for your schedule. After setting‚ press SET again to save your preferences. This feature ensures your devices operate automatically‚ saving energy and effort. The timer is compatible with CFL and LED lights‚ making it ideal for lamps‚ fans‚ and more.
3.3 Understanding the Timer’s Operating Modes
The Woods Timer 50007 features multiple operating modes designed to meet various household needs. The daily scheduling mode allows users to set specific on/off times for devices‚ optimizing energy consumption. A manual override mode is available for making temporary changes without affecting programmed schedules. Additionally‚ there’s a mode specifically for holiday lights‚ simplifying the management of seasonal decorations. These modes not only enhance convenience but also ensure energy efficiency‚ accommodating different lifestyles and preferences effortlessly for a seamless experience.
Troubleshooting Common Issues
Resolve display issues by checking power connections and ensuring proper setup. Address synchronization problems by resetting the timer or reprogramming schedules‚ ensuring accurate operation and reliability.
4.1 Resolving Display Issues
If the display is blank or not showing the correct time‚ ensure the timer is properly plugged in and the outlet is functioning. Check for loose connections and verify that the timer is set correctly. If issues persist‚ reset the timer by pressing and holding the reset button or following the factory reset procedure. Ensure the time is set accurately after resetting. If problems continue‚ refer to the manual or contact customer support for further assistance.
4.2 Fixing Timer Synchronization Problems
If the timer loses synchronization‚ ensure the current time is set correctly by pressing and holding the SET button for 2 seconds. Adjust the hour and minute using the arrows. If issues persist‚ reset the timer by pressing the reset button or following the factory reset process; After resetting‚ reprogram the timer and ensure it is plugged into a stable power source. This should resolve synchronization errors and restore proper functionality.
Safety Precautions and Certifications
The Woods Timer 50007 is CSA certified‚ ensuring safety and compliance with North American standards. Always follow safety guidelines to avoid electrical hazards and ensure proper operation.
5.1 CSA Certification and Compliance
The Woods Timer 50007 holds CSA certification‚ ensuring it meets rigorous safety and performance standards in Canada and the U.S. This certification guarantees the timer’s reliability and compliance with electrical regulations‚ providing users with confidence in its safe operation for automating household devices.
5.2 Important Safety Guidelines for Usage
Ensure the timer is used with devices rated for its capacity to prevent overload. Avoid exposing it to water or extreme temperatures. Only use with compatible CFL or LED lights. Keep the timer out of reach of children and avoid tampering with internal components. Always follow the manufacturer’s instructions for installation and operation to maintain safety and functionality.
Compatibility with Various Devices
The Woods Timer 50007 is compatible with lamps‚ fans‚ and holiday lights. It works seamlessly with CFL and LED bulbs‚ ensuring efficient and reliable performance.
6.1 Using the Timer with Lamps and Fans
The Woods Timer 50007 is designed to work seamlessly with lamps and fans‚ allowing you to automate their operation. It can be plugged into any standard outlet and connected to your devices. The timer supports a wide range of electrical devices‚ making it ideal for controlling lights‚ ceiling fans‚ or other household appliances. Its compatibility ensures smooth operation and energy efficiency‚ while the programmable features help you manage your devices effortlessly throughout the day.
6.2 Compatibility with CFL and LED Lights
The Woods Timer 50007 is fully compatible with CFL and LED lights‚ ensuring smooth operation without flickering or humming. Its advanced design supports energy-efficient lighting solutions‚ making it an eco-friendly choice for modern homes. The timer’s compatibility with these lighting types ensures reliable performance and extends the lifespan of your bulbs. With CSA certification‚ it meets safety standards for use with a variety of lighting setups‚ providing peace of mind for users.
Resetting the Woods Timer 50007
Resetting the Woods Timer 50007 restores factory settings and clears stored programs. Press and hold the SET button for 5 seconds‚ then release and press CLR to confirm.
7.1 Resetting to Factory Settings
To reset the Woods Timer 50007 to factory settings‚ press and hold the SET button for 5 seconds until the display flashes. Release the SET button‚ then press the CLR button to confirm. This action will erase all programmed settings‚ returning the timer to its default state. Ensure the timer is unplugged before resetting to avoid any interference. Once reset‚ the timer will need to be reprogrammed with the current time and desired on/off schedules.
7.2 Clearing Stored Programs
To clear stored programs on the Woods Timer 50007‚ press and hold the PROG button until the display shows “PROG.” Use the arrow buttons to scroll through each program. Press and hold the CLR button to delete the selected program. Repeat for all programs you wish to remove. After clearing‚ exit programming mode to save changes. This ensures the timer returns to a blank schedule‚ ready for new programming.
Additional Resources
8.1 Downloading the Official Manual
8.2 Finding Online Tutorials and Guides
Online tutorials and guides for the Woods Timer 50007 are available on platforms like YouTube and forums. Channels such as Simon Herberst offer detailed videos on programming and troubleshooting. Websites like SwagDaddy provide step-by-step instructions and FAQs. These resources cover basic setup‚ advanced features‚ and resolving common issues. They are ideal for users seeking visual or written guidance to maximize the timer’s functionality and address specific needs.
